POWER Solution

CYSALYS, as a TETRADIS dedicated brand, is specialized in energies regarding telecommunication field. It develops different types of energy solutions in order to answer the needs of telecommunication players and others isolated sites.

  • Autonomous and hybrid energy production solutions (solar, generator, batteries) dedicated to mobile phone networks: BETI range (0,8 to 9 kW)
  • Autonomous solar energy production solution dedicated to repeaters, to equipment that consume less energy (repeater, single sector, LTE, transmission site…): BSE range (100 to 800 W),
  • Less powerful autonomous energy production solutions for small power installations dedicated IoT networks, surveillance video…: BS2P range (5 to 100 W),
  • Tailors-made solutions that adapt to the needs and the customer site environment
  • 1

    SHP-Unit Smart Hybrid
    Power Unit

  • 2

    High efficiency
    Photovoltaic panels

  • 3

    Secure fuel tank

  • 4

    Diesel generator

  • 5

    Energy Management
    System CYBOX

  • 6

    Telecom equipment cabinet

  • 7

    Deep cycling batteries

  • 8

    SWU : Solar Wind Units

  • 9

    Photovoltaic shade

  • 10

    SWU TGBT cabinet

  • 5

    Energy Management
    System CYBOX

  • 7

    Deep cycling batteries

  • 11

    LP2S : Low Power Solar System

  • 12

    Low power photovoltaic panels

  • 13

    LP2S electrical box

  • 14

    Video protection system

SHP-Unit Smart Hybrid Power Unit
Power 1 to 9 kW
SHP-Unit Smart Hybrid Power Unit
  • Allows to power infrastructures up to 9kW, in autonomy
  • Reliability and redundancy of sources
  • OPEX reduction up to 80% Vs GE (fuel and maintenance), and also CO2 rejections
  • Quick plug and play installation
  • Local management and remote supervision
  • Reinforced security (metal structure)
  • Temporary or permanent use
  • Optional stand-alone chassis
1
High efficiency Photovoltaic panels
SHP-Unit : Smart Hybrid Power Unit
High efficiency Photovoltaic panels
  • Solar power of 3kWp integrated on the top
  • Panel yeld > 20%
  • Limited footprint
  • Reinforced protection against theft
  • Quick and simplified assembly on site
2
Secure fuel tank
SHP-Unit : Smart Hybrid Power Unit
Secure fuel tank
  • 1500-liter tank as standard
  • Fuel level supervised and alarm in case of low threshold
  • Leakage sensor
  • Catchment system at the top of the tank for cleaner fuel
  • Reinforced security (access, metal structure, not visible)
3
Diesel generator
SHP-Unit : Smart Hybrid Power Unit
Diesel generator
  • Power adapted to needs for optimizing the load rate (22kVA ESP for BETI 4kW)
  • Remote control and supervision of alarms
  • Soft starts and stops to extend service life
  • Monitoring of operating hours, alert for preventive maintenance
  • Option : Long run kit for 1000h maintenance
4
Energy Management System CYBOX
SHP-Unit and SWU
Energy Management System CYBOX
  • Local and autonomous management
  • Intelligent algorithm for OPEX optimization
  • Modular and scalable system
  • Supervised dashboard H24 and 7D
  • Reduction in the number of interventions
  • Data archiving for analysis and exploitation
  • Option : Configuration adaptable to customer request
5
Energy Management System CYBOX
SHP-Unit and SWU
Energy Management System CYBOX
  • Local and autonomous management
  • Intelligent algorithm for OPEX optimization
  • Modular and scalable system
  • Supervised dashboard H24 and 7D
  • Reduction in the number of interventions
  • Data archiving for analysis and exploitation
  • Option : Configuration adaptable to customer request
5
Telecom equipment cabinet
SHP-Unit : Smart Hybrid Power Unit
Telecom equipment cabinet
  • TGBT with its electrical protections
  • Modular and « hot swapable » swap battery charger
  • Modular solar regulator and « hot swapable »
  • Integrated lightning protection
  • Departure of customer equipment protected in -48Vdc
  • Option : 230VAc inverter
  • Option under metering
6
Deep cycling batteries
SHP-Unit and SWU
Deep cycling batteries
  • Type of batteries adapted to needs (lead, Li)
  • Autonomy adapted to consumption
  • Lifespan :
    - Pb batteries: 2400 cycles at 60% Dod
    - Li batteries: 6000 cycles at 80%
  • Temperature management to optimize lifespan
7
Deep cycling batteries
SHP-Unit and SWU
Deep cycling batteries
  • Type of batteries adapted to needs (lead, Li)
  • Autonomy adapted to consumption
  • Lifespan :
    - Pb batteries: 2400 cycles at 60% Dod
    - Li batteries: 6000 cycles at 80%
  • Temperature management to optimize lifespan
7
SWU : Solar Wind Units
Power 100 to 800 W
SWU : Solar Wind Units
  • Allows to power infrastructure from 100 to 800 W
  • 100% Renewable Energy autonomous solution (no CO2 emissions)
  • Power and autonomy adjustable to the needs of the equipment to be supplied
  • Modular solution easy to install
  • Minimized operating costs (OPEX)
8
Photovoltaic shade
SWU : Solar Wind Units
Photovoltaic shade
  • Modular and scalable panels structure, adjustable to the needs of the equipment to be supplied
  • High efficiency solar panels
  • Hot-dip galvanized metal structure
  • Easy to install solution
9
SWU TGBT cabinet
SWU : Solar Wind Units
SWU TGBT cabinet
  • TGBT with its electrical protections
  • IP 55 outdoor enclosure
  • Modular solar regulator adapted to needs
  • Modular battery charger adapted to needs
  • Integrated lightning protection
  • Departure of customer equipment protected in -48Vdc
  • 230 vAC inverter option
10
LP2S : Low Power Solar System
Power 5 to 100 W
LP2S : Low Power Solar System
  • Complete autonomous solar energy kit
  • Ideal for powering your Gateway IoTs, video surveillance cameras or other low-consumption equipment.
  • Avoids the cost of infrastructure work for the electrical connection and the monthly subscription
  • Complete packaged solution, easy to install
  • Autonomy 3 to 5 days, adjustable to your needs
11
Low power photovoltaic panels
LP2S : Low Power Solar System
Low power photovoltaic panels
  • Panel solar power adapted to needs
  • Limited panels footprint for installation on existing support and visual integration
  • Aluminum structure (mounting kit on mast or wall) for extended service life
  • Quick and simplified assembly on site
12
LP2S electrical box
LP2S : Low Power Solar System
LP2S electrical box
  • IP 55 outdoor electrical box
  • Modular solar regulator adapted to needs
  • Modular battery charger adapted to needs
  • Departure of customer equipment protected in 12, 24 or 48Vdc (according to customer needs)
13
Video protection system
Powered by the BS2P
Video protection system
  • 1080P IP Camera - 360° Pan Rotation
  • 1/2.9" CMOS Sensor
  • Illumination : IR 100m
  • Motion Detection and Privacy Masking
  • Other type of infrastructure that can be powered by the BS2P: various security systems, IoT networks, etc.
14
