FTTH solutions for the deployment of ultra-high-speed broadband networks

TETRADIS, a specialist in ultra-high-speed broadband networks, offers a comprehensive range of FTTH solutions designed for telecoms operators, system integrators and network deployment companies.

Designed to meet the demands of telecommunications infrastructure, our solutions support every stage of fibre-optic network deployment, right through to the connection of end-users. Compliant with the current recommendations and regulations defined by ARCEP, our products guarantee the performance, reliability and longevity of the deployed infrastructure.

Thanks to its hands-on expertise and in-depth understanding of the challenges faced by operators, TETRADIS contributes to the construction of robust, scalable Ultra-High-Speed Broadband networks capable of meeting the growing connectivity needs of local areas.

  • 1

    Street cabinet and equipments

  • 2

    Underground optical connection buried

  • 3

    Watertight fiber closure

  • 4

    Outdoor terminal box

  • 5

    Optical connection indoor/outdoor

  • 6

    Indoor terminal box

  • 7

    Indoor secure optical box

  • 8

    Indoor optical connection

  • 9

    Customer terminal box


Indoor optical connection
Riser cable Home-PACe
Riser cable Home-PACe
  • From 24 to 288 FO 250μ
  • Single-mode free structure
  • Riser cable Home-PACe
  • LSOH sheath
  • Compact Tube: 2 to 24 tubes
8
Underground optical connection buried
Cable compact tubes
Cable compact tubes
  • Singlemode cable CCU or UNC
  • Compact unitube structure, sheath LSOH, PeHD, or Armored PeHD, depending on the type of cable
  • Up to 24 ELine RJ45 modules
  • From 1 to 288 FO, depending on the type of cable
  • 9/125, G652 or G657, depending on the type of cable
2
Optical connection indoor/outdoor
Cable Compact Tube UNC
Cable Compact Tube UNC
  • Single mode cable 9/125 G657
  • From 1 to 4FO depending on the structure, semi-tight or free
  • PeHD sheath undressable
5
Street cabinet and equipments
Modul’O HD
Modul’O HD
  • Capacity : 31, 62 ou 93U
  • Bio-climatic concept : double-skin IP55 with lifting eyelet
  • Intelligent garter management
  • Removable side panels from the inside
  • Structure IK09
  • Treated steel and high performance paint RAL 7035
  • Equipments for cabinet : Tiroir optique équipe raccords et pigtails : TOM or TOP range, Optical fan-out, TGBT block, Inverter, Active materials
1
Outdoor terminal box
FIST BD Taille 1
FIST BD Taille 1
  • IP53 plastic wall box
  • 1 to 4 12FO splice trays
  • From 12 to 48 splices
4
Indoor terminal box
RJ45 connector ELine Cat.6A
PBPO/C with connectors
  • Compact housing with slide cover
  • Up to 12 SC or SC-APC connections
  • 2 splicing cassettes
  • From 12 to 48 splices
  • Material: thermoplastic
  • IP40 and IK08
6
Indoor secure optical box
COS
Indoor secure optical box
  • Securable metal box
  • Wall mount, can be attached to each other
  • Singlemode or multimode connector
  • Up to 48 simplex SC (or ST / FC on request)
  • Up to 48 Mono pigtails. Grade B1 or Multimode
  • Up to 4 12FO cassettes
7
Watertight fiber closure
FIST GCO2
FIST GCO2
  • Watertight fiber closure
  • Connecting cables on the cob
  • 6 to 16 round trips, depending on the model
  • from 336 to 1344 splices, depending on the model and type of cassette
3
Customer terminal box
PTO
Customer terminal box
  • Terminal Optic Terminal 1 to 4FO
  • Simplex SC and duplex LC connectors
  • G652D fiber
  • With cable length of 2.50m
  • Wall mounting, by double-sided adhesive, on built-in boxes or DIN rail
  • From 1 to 4 SC-APC fittings (depending on version)
9

Ensuring network resilience and performance

The resilience of telecoms networks is crucial to ensuring the continuity of digital services across the country. It depends on the infrastructure’s ability to remain operational and to be restored quickly in the event of an incident.

To address these challenges, TETRADIS supports operators and network providers in maintaining their networks in operational condition through products for repairs, monitoring of interventions at NRO shelters, and optimising infrastructure operations.

Committed to responsible digital practices, TETRADIS also helps reduce the carbon footprint of networks by offering solarisation solutions for network infrastructure, thereby enhancing their energy self-sufficiency and resilience.
